Technical description
5.2

Control elements

You will find the following control elements on the transmitter module:
No. in
fig. 6, page 5
1
2
3
4
5
6
7
8
The receiver module has the following control elements:
No. in
fig. 7, page 5
1
2
3
4
5
6
24
Meaning
Antenna connection
Pairing button
Operating mode display:
 LED glows red when signals are being transmitted
 LED flashes red when the components are being paired
Camera connection
Blue cable (CAMERA POWER TRIGGER): voltage supply for
camera and switch input for protective cover of CAM80 (see
page 28)
Green cable (REVERSE TRIGGER): control cable for activating
the pairing signal
Red cable (DC INPUT): Connection to the positive terminal of the
voltage supply; preferably ignition plus
Black cable (GND): Connection to the negative terminal of the
voltage supply or earth
Meaning
Antenna connection
Pairing button
Operating mode display:
 LED glows red when signals are being transmitted
 LED flashes red when the components are being paired
Monitor connection
Green cable (REVERSE TRIGGER): control cable for activating
the pairing signal
Black cable (GND): Connection to earth
VT100DIG
EN
