Type
A Screw
B Washer
C Nut
Hex wrench
Connect the console cables: Pull the cable through the right stand of the
post. Pull the cable out of the right stand and attach it to the top of the
stand. Then remove the auxiliary wire. Place the right post on the frame.
Attach the post to the frame with part A, B & C (2 pieces each). Make sure
that all screws and washers are in place and tighten them lightly. Repeat the
steps for the left post.
Note: Tighten the screws only after mounting the front pulse sensor bar.
Take care not to damage the sensor cables during installation.
Step 2
Required Hardware
Illustration
Button Head Socket Bolt
Flat washer (Ø10)
Nylon nuts (M10)
Console
cable
Open wrench
Qty.
4
4
4
