CoolAir RTX1000, RTX2000
7.3

Removing the roof hatch

Proceed as follows (fig. 6):
➤ Remove all screws and fixings for the existing roof hatch.
➤ Take out the roof hatch.
➤ Remove the sealant around the opening so that the surface is clean and free
of grease.
I
NOTE
Dispose of all waste material, glue, silicon and seals separately. When doing
so, follow the waste disposal requirements applicable in your local area.
7.4

Preparing the unit

A
NOTICE!
When preparing the unit on the work surface, make sure it is secured against
falling off.
Make sure that the work surface is clean and level to ensure that the unit is not
damaged.
Proceed as follows (fig. 7):
➤ Place the parking cooler on a work surface with the casing facing down.
➤ Screw the 6 self-tapping M8 threaded plugs into the blind holes marked "6".
To do so, use the 1/4" bit supplied.
➤ Screw the 4 self-tapping M6 threaded plugs into the blind holes marked "7".
Use a 5 mm hexagon bit to do so.
7.5

Attaching the seal for the cab roof

A
NOTICE!
Ensure that the surface where the seal between the unit and the cab roof is to
be glued is clean (free of dust, oil, etc.).
➤ Glue the sealing strip to the cab roof (fig. 8 A).
Follow the contour of the roof hatch opening. The join between the ends of
the seal should be at the back.
➤ Apply a flexible, non-hardening butyl sealant (e.g. SikaLastomer-710) to the
join between the ends of the sealing strip and to the top edge of the sealing
strip (fig. 8 B).
EN
Installation
9
