Installation
• The top cowl of the parking cooler can be painted (fig. 3). The
manufacturer recommends that the painting is done by a specialist paint
shop.
• Before installation, check with the vehicle manufacturer whether the vehicle
body is designed for the static weight of the parking cooler and the dynamic
loads created by it when the vehicle is in motion. The manufacturer of the
parking cooler accepts no liability whatsoever in that regard.
• The downward slope of the roof in forward direction in the area where the
unit is installed must not be more than:
– RTX1000: 8°
– RTX2000: 20°
• The assembly parts supplied must not be modified during installation.
• The ventilation openings must not be covered over (minimum distance from
other external attachments: 100 mm).
• Follow the vehicle manufacturer's guidelines when installing the system and
establishing the electrical connections.
I
NOTE
After installation of the system, the pre-set parameters on the system software
must be checked (chapter "Configuring the system software" on page 12).
7.2

Creating the opening (if necessary)

I
NOTE
To simplify the task of creating the opening, there is a template integrated in
the packaging of the installation kit.
➤ Create an opening measuring 505 mm x 500 mm with rounded corners with
a radius of R25 (fig. 5, arrow = forward direction).
I
NOTE
Dispose of all waste materials separately. When doing so, follow the waste
disposal requirements applicable in your local area.
