Installation
• When installing the system and making the electrical connections, observe
the guidelines from the body manufacturer.
• Pay attention to the connection plan for the device:
No. in
fig. 0, page 8
!
WARNING!
Before installing the air conditioning roof unit, all connections to the battery of
the vehicle must be disconnected.
Non-observance of this regulation can result in danger of electrocution.
!
CAUTION!
Improper installation of the air conditioning roof unit can result in irreparable
damage to the device and put the safety of the user at risk.
The manufacturer will not be held liable for claims if the air conditioning roof
unit is not installed according to this installation manual. That applies to mal-
functions and the safety of the air conditioning roof unit, in particular to injuries
and damage to property.
I
NOTE
After installing the unit, the specified parameters of the unit software must be
checked (chapter "Configuration of unit software" on page 20).
16
Designation
1 Control pad
2 Connection cable
3 Room temperature sensor
4 Earth
5 Klickson (compressor)
6 Compressor
7 Condenser fan
8 Vaporiser fan
9 Earth
10 25 A fuse
11 2 A fuse
12 4 A fuse
CoolAir RT780
EN
