LoRaWAN 863-870 ANALOG PWR - Guide utilisateur / User guide version V2.0.2

4.1.7 Summary of the conditions of the transmission of the uplink frames

The table below summarizes the conditions of the transmission of the different uplink frames:
Code
0x10 Product configuration data frames
0x11
FR
0x12
0x13
0x14
0x20 Frames of information on the network
configuration
0x30 Keep Alive frame
EN
0x31 Reply frame to a register value request in
a downlink frame
0x42 Data Frame

4.2. Downlink frames

LoRaWAN technology makes it possible to transmit information to the product from the network (downlink frame).
The class A of the LoRaWAN specification allows the product to receive information from the network by proposing two listening windows after
each uplink communication (uplink frame).

4.2.1 Product configuration request frame

This frame allows us to inform the product via the network that it must resend the product configuration uplink frame (0x10).
0
Code
0x01

4.2.2 Network configuration request frame

This frame allows us to inform the product via the network that it must resend the network configuration uplink frame (0x20).
0
Code
0x02
Description
1 2
X X
1 2
X X
Sending conditions
• Start-up of the product
• Exit from the configuration mode (AT Command)
• Reception of a downlink frame 0x01
• Periodically if the inputs are disabled (period defined by the register 300)
• Start-up of the product
• Exit from the configuration mode (AT Command)
• Reception of a downlink frame 0x02
• Periodically in «event» mode
• Reception of a downlink frame 0x40
• Start-up of the product
• Event on an digital input configured in event mode
• Passing a threshold (event mode)
• The end of the period on input configured in periodic mode
3 4
PAYLOAD
X X
3 4
PAYLOAD
X X
5 6
X X
5 6
X X
7
X
7
X
Page 74 of 87
