6. SAFETY INFORMATION

Motor safety switch

The motor safety swich turns off the motor in the event of
a capacity overloaded. The function of the motor safety
switch may not be taken out of operation.
If the motor safety switch has turned off the appliance,
proceed as follows:
1. Disconnect the appliance from the power supply
2. Correct the caue for the capacity overload.
3. After a cooling time of 15 minutes, connect it again
to the power supply and start the appliance up again

7. DESCRIPTION AND PACKAGE CONTENTS

The package contains (fig. 1):
1x machine and scarifying roller
2x bottom part of the handle
2x middle part of the handle
4x screws and knurled nuts
1x top part of the handle
1x safety switch
1x grass collecting bag
1x collecting bag frame
1x cable holder
2x cable clips
1x rake roller
2x self-tapping screws
1x operating instructions
1x Optional: Allen key
NOTE: make sure that the Machine and accessories in
the package are not damaged.

8. ASSEMBLY

Always disconnect plug from mains before
assembly and setting up
Assembling the handle (figs. 2, 3 and 4)
• Slide the two bottom handle parts (1c) into the locating
holes in the housing until they reach the stops (fig. 2).
• Fasten the handles with the 2 self-tapping screws (9)
(fig. 3).
• Fit the two middle handle parts (1b) to the lower parts
of the handle with the help of the bolts (4b) and knurled
nuts (4a) (fig. 4).
• Guide the cable holder (3) over the top part of the han-
dle (1a) on the switch side and fasten this to the middle
handle parts with the bolts and knurled nuts (fig. 4).
GB | Operating Instructions
Fit the safety switch (figs. 5 and 6)
• Remove the cover by loosening the 2 screws.
• Fit the switch with the holder and the screws through
• Fasten the mains cable to the handle with the clips
Assembling the grass collection box (fig. 7)
• Slide the collecting bag (6) over the metal frame and
• Lift up the protective cover (5).
• Hang the grass collecting box in place by hooking the
Note: If you do not wish to collect the grass, the machine
can also be operated without the collecting bag. In this
case the protective cover (5) folds downwards.
Adjusting the height of the wheels (fig. 8)
• Use the adjustment arm (7) of the machine body for
• Pull the adjustment arm (7) away to move it along the
• Select regulation from among the 4 options.
• Release and Insert the adjustment arm (7) into the
Changing the working rollers (scarifier/rake) (fig. 9
and 10)
Before starting work, pull the mains plug out of the outlet
and wait until the roller has come to a standstill.
• Use an Allen key to replace the working roller.
• Turn the machine over and loosen the two screws (A)
• Lift the roller on the bearing side and pull it out of the
• Lift the complete roller upwards out of the machine.
• Pull the bearing shell (C) (fig. 9) off the roller. Fit the
• Slide the square drive bushing of the new roller onto
• Fit the other end of the work roller with the bearing
• Fasten the roller with the two screws (A) and tighten
GB-8
the 2 holes on the right side of the handle.
(12) (fig. 6)
fasten it to the frame with the clips (fig. 7).
2 hooks into the corresponding holes on the discharge
opening (13).
adjusting height of wheels to select the height for work-
ing.
slot.
cross hole of every position to lock coupling between
arm and cover.
Danger! The roller can cause injuries. Wear work
gloves.
on the bearing shell (C) (fig. 9).
drive (B) (fig. 9).
bearing shell (C) to the new work roller (fig. 10).
the driveaxle (B) of the machine (fig. 10).
shell (C) into the corresponding mount on the machine.
these with the Allen key (fig. 10). Then turn the ma-
chine back over again.
