6. SAFETY INFORMATION
Motor safety switch
The motor safety switch turns off the motor in the event
of a capacity overloaded. The function of the motor safety
switch may not be taken out of operation.
If the motor safety switch has turned off the appliance,
proceed as follows:
1. Disconnect the appliance from the power supply
2. Correct the caue for the capacity overload.
3. After a cooling time of 15 minutes, connect it again
to the power supply and start the appliance up again

7. DESCRIPTION AND PACKAGE CONTENTS

The package contains (fig. 1):
1x machine and scarifying roller
1x bottom part of the handle
2x middle part of the handle
4x screws and knurled nuts
1x top part of the handle
1x grass collecting bag
1x collecting bag frame
1x cable holder
2x cable clips
1x rake roller
2x quick-release fasteners
1x allen key
1x operating instructions
NOTE: make sure that the Machine and accessories in
the package are not damaged.

8. ASSEMBLY

Always disconnect plug from mains before
assembly and setting up
Assembling the handle (figs. 2, 3 and 4)
1. Slide the cable strain relief (3) onto the bottom part of
the handle (1c).
2. Insert the bottom part of the handle (1c) into the
swivel block (A). Then insert the quick clamp lever (9)
with the screw from the outside through the openings
in the lower part of the handle (1c). Screw the quick
clamp screw (9) into the mounting (B) on the housing.
3. Press the quick coupler lever (9) with light pressure
to lock (loosen the screw a little or tighten it a little if
required).
4. The height of the handle can be changed between 4
positions by loosening the quick clamp (9).
5. Insert the two fastening screws (4b) from the inside
through the openings in the bottom part of the handle
(1c) and secure the middle parts of the handle (1b)
with two knurled nuts (4a).
GB | Operating Instructions
6. Insert the two fastening screws (4b) from the inside
7. Tighten all screws hand-tight.
8. Fasten the mains cable to the handle with the clips
Assembling the grass collection box (fig. 5 and 6)
• Slide the collecting bag (6) over the metal frame and
• Lift up the protective cover (5).
• Hang the grass collecting box in place by hooking the
Note: If you do not wish to collect the grass, the machine
can also be operated without the collecting bag. In this
case the protective cover (5) folds downwards.
Adjusting the height of the wheels (fig. 7)
The machine has stepless height adjustment. The de-
sired working depth can be set by turning the adjusting
knob (7).
Changing the working rollers (scarifier/rake) (fig. 8,
9 and 10)
Before starting work, pull the mains plug out of the outlet
and wait until the roller has come to a standstill.
• Use an Allen key (14) to replace the working roller.
• Turn the machine over and loosen the two screws (A)
• Lift the roller on the bearing side and pull it out of the
• Lift the complete roller upwards out of the machine.
• Pull the bearing shell (C) (fig. 9) off the roller. Fit the
• Slide the square drive axle of the new roller into the
• Fit the other end of the work roller with the bearing
• Fasten the roller with the two screws (A) and tighten

9. OPERATING INSTRUCTIONS

HINTS AND SUGGESTIONS
How to use the scarifier (using scarifying roller 10)
• By scarifying you remove the hardened surface, grass
GB-8
through the openings in the top part of the handle (7)
and secure these to the middle parts of the handle
(1b) with two knurled nuts (4a).
(12) (fig. 4)
fasten it to the frame with the clips (fig. 5).
2 hooks into the corresponding holes on the discharge
opening (13).
Danger! The roller can cause injuries. Wear work
gloves.
on the bearing shell (C) (fig. 9).
drive (B) (fig. 9).
bearing shell (C) to the new work roller (fig. 10).
drivebushing (B) of the machine (fig. 10).
shell (C) into the corresponding mount on the machine.
these with the Allen key (fig. 10). Then turn the ma-
chine back over again.
Always keep to instructions on safety and
current rules and regulations.
felt and flat-growing weeds and the crusted over grass-
roots are loosened up. The lawn will start to breath
again and assimilate the nourishing substances, oxy-
gen and water. This also prevents the establishing of
bacteria in the lawn felt during the wintertime.
