GENERAL MAINTENANCE
Avoid using solvents when cleaning plastic parts. Most
plastics are susceptible to damage from various types of
commercial solvents and may be damaged by their use. Use
clean cloths to remove dirt, dust, oil, grease, etc.
WARNING:
Do not at any time let brake fluids, gasoline, petroleum-
based products, penetrating oils, etc., come in contact
with plastic parts. Chemicals can damage, weaken, or
destroy plastic, which may result in serious personal injury.
WARNING:
Blades are sharp. To reduce the possibility of serious injury,
always wear gloves when performing maintenance on the
hedge trimmer blades. When handling blade assembly,
do not place your hand or fingers between blades or in
any position where they could get pinched or cut. NEVER
touch blades or perform maintenance while the hedge
trimmer attachment is attached to the engine.
BLADE CARE
 Lubricate the cutting blade after each use.
 Periodically inspect the blade for damage and wear.
 If it becomes necessary to have the blade replaced, take
the hedge trimmer to a qualified service center.
This product has a Three-year Limited Warranty for personal,
family, or household use (90 days for business or commercial use).
For warranty details, visit www.ryobitools.com
MAINTENANCE
or call (toll free) 1-800-860-4050.
8 — English
LUBRICATING THE BLADE
See Figure 6.
For easier operation and longer blade life, lubricate the blade
before and after each use.
 Lay hedge trimmer on a flat surface.
 Use a brush to remove debris or clippings from the blade.
Wipe any remaining debris away with a clean cloth.
 Apply light weight machine oil along the edge of the top
blade. Wipe any excess oil from the blade.
Occasionally, you should oil the hedge trimmer during use.
Before oiling, stop the hedge trimmer, remove the attach-
ment, then oil. You can then resume trimming. Do not oil
while hedge trimmer is running.
ATTACHING THE STORAGE HANGER
See Figure 7.
There are two ways to hang the attachment for storage.
 To use the hanger cap, push in the button and place the
hanger cap over the end of the attachment shaft. Slightly
rotate the cap from side to side until the button locks into
place.
 The secondary hole in the attachment shaft can be used
for hanging purposes as well.
STORING THE ATTACHMENT
 Clean the attachment thoroughly and lubricate before
storing.
 Store the attachment indoors in a dry, well-ventilated
place that is inaccessible to children.
 Keep away from corrosive agents such as garden chemi-
cals and de-icing salts.
 Always place the scabbard on the cutting blade before
storing or when the attachment is not in use.
