ENGLISH
Description and operation
Fig. 1÷2
The appliance you have purchased has been
specifically designed for continuous mechanical
extract ventilation of dwellings with between 2 and 7
rooms (from F2 to F7 types under French legislation).
The
premium
quality
components used as well as the advanced air design
of the aerodynamic sections ensure that ventilation
requirements are met.
The appliance must generally be positioned in the loft
or a suitable cupboard and, if possible, in a central
position in relation to the extract vents.
It can be installed on a wall, floor or ceiling, using a
support or fixed with suspension wires to the 4
anchor points (fig. 5).
Air extraction and circulation with this appliance is
quiet and uninterupted.
Stale air is extracted via the fixed extract grille in the
non-habitable "wet" rooms (kitchens, utilities,
bath/shower rooms and WCs).
A minimum 10 mm. gap at the bottom of the doors
allows the air to circulate correctly.
In the kitchen, if necessary, it is possible to switch the
fan onto maximum speed to extract cooking smells
and condensation. Afterwards, turn the control back
onto low speed continuous operation.
Warning
Ventilation must be continuous. Never stop the
ventilation unit, except of course for maintenance or
cleaning.
The device is equipped with electronically controlled
relative humidity sensors with threshold set during
installation.
The device is equipped with a three-speed AC motor
with thermal overload cut-out and shaft turning in ball
bearings to guarantee long lasting continuous service
(at least 30000 h) at the maximum data plate
temperature.
These appliances have been
designed for use in residential
properties.
Distribution and elements of the appliances:
VORT PENTA HCS (fig. 1a)
• 1 body with inlet and outlet Ø 125, and 5 vents Ø
80;
• 2 regulators for bathroom intakes Ø 80 equipped
with fixed extract grille of 30 m
• 4 blanking plugs,
• 2 suspension wires,
• 1 support.
By purchasing the specific accessories it is possible,
according to need, to convert the appliance into a
configuration with up to 5 room regulators by adding
another 3 bathroom intakes Ø 80.
KIT VORT PENTA (fig. 1b)
(It is not available in the UK)
• 1 body with inlet and outlet Ø 125, and 5 vents Ø
80;
• 2 regulators for bathroom intakes
of
the
materials
and
3
/h
80 equipped
Ø
3
with valves of 30 m
/h
• 2 regulators for bathroom intakes
3
with valves of 15 m
/h
• 1 fixed extract grille
Ø
• 2 fixed extract grilles
• 1 switch,
• 4 blanking plugs,
• 2 suspension wires,
• 1 support.
By requesting the specific accessory it is possible,
according to need, to convert the appliance into a
configuration with up to 5 bathroom regulators by
applying 1 bathroom intake
KIT PENTA DESIGN HCS (fig. 1c)
(Only for FRENCH market)
• 1 body with inlet and outlet Ø 125, and 5 vents Ø
80;
• 2 regulators for bathroom intakes
3
with valves of 30 m
/h
• 2 regulators for bathroom intakes
3
with valves of 15 m
/h
• 1 fixed design extract grille
• 2 fixed design extract grilles
• 1 switch,
• 4 blanking plugs,
• 2 suspension wires,
• 1 support.
By requesting the specific accessory it is possible,
according to need, to convert the appliance into a
configuration with up to 5 bathroom regulators by
applying 1 bathroom intake
Valvles identification
Fig. 2.
Erp Regulation: the reference curve for compliance
with reg.1253/2014 is the MAX curve relative to the
Vmax that can be set as per the wiring diagram
shown in fig.16.
Safety
Warning:
!
this symbol indicates that care must
be taken to avoid injury to the user
• Do not use this appliance for functions other than
those described in this booklet.
• After removing the appliance from its packaging,
ensure that it is complete and undamaged:
If in doubt contact a professionally qualified
electrician or contact Vortice*.
Do not leave packaging within the reach of children
or differently able persons.
• Certain fundamental rules must be observed when
using any electrical appliance: a) Never touch
appliances with wet or damp hands; b) Never touch
appliances while barefoot; c) Never allow children to
touch or play with the appliance; d) The use of this
appliance by incapacitated people shold be under
supervision.
• Do not operate the appliance in the presence of
inflammable vapours (alcohol, insecticides, petrol,
80 equipped
Ø
125,
80,
Ø
80.
Ø
80 equipped
Ø
80 equipped
Ø
125,
Ø
80,
Ø
80.
Ø
7
