Open the locking device (K)
25
the joint brush unit (J), as shown in
the illustration, and remove the joint
brush unit.
Unscrew the hexagon socket screw
26
2-3 turns so far out of the joint brush
housing, until safety guard (H) can
easily be twisted and pulled off.
Now press lock button (Q) which
27
blocks the drive shaft and unscrew the
hexagon socket screw, which fixes the
joint brush (J), from the drive shaft
( ).
Remove the disc from the joint brush.
ATTENTION! Improper use of the
device poses a risk of damage to
property!
You should therefore observe the
following safety instruction:
Never activate the lock button (Q)
when the joint brush is running.
Pull the joint brush (J) from the flange
28
on the shaft and exchange it for a new
one.
Assembly is carried out in reverse
29
order (
After maintenance or cleaning ensure
that all screws, bolts, nuts and safety
devices are secure and assembled.
7

Decommissioning

& Storage
7.1 Decommissioning
Figure 30
Take the device out of operation by
releasing the ON/OFF safety switch (D)
in the handle.
Disconnect the device from the power
supply.
of
).
CAUTION! RISK OF INJURY FROM
RUNNING BRUSHING TOOL!
Never lift the device off the ground
whilst switching it off as there is
danger of entanglement!
Do not put the device down on the
30
brush during work breaks or after use
as this will damage the bristles.
Always hang the device up or lie it
down as shown in the illustration.

7.2 Storage

CAUTION! You may be exposed to
hazards that could injure you
when handling the device.
You must therefore store the
device away from children.
Remove any dirt and debris.
Store the device hung up, dry and
protected from frost.
8 Maintenance & Cleaning
CAUTION! RISK OF BURNS
CAUSED BY HOT PARTS!
During assembly or conversion work
the drive parts of the device or
components can still be very hot and
may cause burns. It is therefore
important to observe the following
safety instruction:
Wear protective gloves during
maintenance and cleaning!

8.1 Cleaning

WARNING! RISK OF DEATH
DUE TO ELECTRIC SHOCK!
If the energised device comes into
contact with water, there is a risk of
seri ous injury or death!
29
