Assembly; Commissioning; Operation - Gloria MultiBrush SpeedControl Mode D'emploi

RZ_MULTIBRUSH_DE_GB_FR_NL_978410-1_Text_GB 10.11.16 15:55 Seite 25
5

Assembly

Figures 1 - 6
NOTE!
Your device is supplied with the
1
surface brush pre-assembled.
Loose parts supplied must be
as sembled accordingly when
working with the joint brush.
After removing from the packaging,
loosen screw connection (G)
Next, turn handle (A) 45° as shown in
fig ure
3
the telescopic tube (F) according to
your body height, as illustrated.
5 locking positions are available.
In the selected position, turn handle
4
(A) a further 45° and tighten the
height of the telescopic tube (F) with
the screw connection (G) by hand.
As the device should always be
guided and operated with two
hands, fit the additional handle (E) as
shown in the figure
height and screw the additional
handle (E) tightly into place
6

Commissioning

WARNING! BEFORE USE OBSERVE
CHAPTER 2 "FOR YOUR SAFETY".
ATTENTION! Improper use of the
device poses a risk of damage to
property!
You should therefore observe the
following safety instructions:
Clean the roller/joint brush (N/J)
before each cleaning operation.
.
2
and adjust the length of
, adjust the
5
.
6
The air inlet openings on the
motor/gear unit (L) must not be
blocked or covered.
Check on a small, if possible hidden
area, that the ground to be cleaned
will not be damaged by the brush-
ing action.
Never use the device too long on
one spot, always guide at walking
pace.

6.1 Operation

Figures 7 - 11
Slide the loop of the extension cable
7
into the designated cable strain relief
(B) in the handle (A) and fix it in the
designated clip.
NOTE!
The performance of the equipment
may decrease if unnecessarily long
extension cables (>25 m) are used.
If cable reels are used, unroll the
en tire cable.
The cross-section of the cable used
must be 1.5 mm
2
Always place the device parallel on
8
the ground which is to be cleaned.
Identify the most comfortable but also
most effective working angle for your-
self and then adjust the 5 click-stop
safety guard (O) so that the rubber lip
is just above the ground.
Make sure that the surface to be
cleaned is free from debris e.g. stones,
screws etc., which could be flung up.
Use an extension cable to connect the
9
device to a power outlet (230 V AC).
CAUTION! RISK OF INJURY FROM
ROTATING BRUSHING TOOL!
Never start the device in a tilted
position!
