Table 8: Input Connection; Figure 11: Example Of Input Connections - DAB PWM 203 Mode D'emploi

In Figure 11 and Table 8 show the input connections.
Voltage-free
I1
I2
I3
I4
ENGLISH

Figure 11: Example of input connections

Input wiring (J5)
input connected to voltage-free contact
contact input between pins
11 - 17
11 - 15
11 - 14
11 - 12

Table 8: Input connection

Jumper
16 -18
16 -18
13 -18
13 - 8
81
input connected to voltage
signal
Signal connection pin
16-17
15-16
13-14
12-13
