. . Display E
Name of components
X Increase support
In the walk assist mode: switch o the
walk assist
Y Decrease walk assist
Press and hold: switch after walk assist
mode
In the walk assist mode: Activate walk
assist
A Switch display of cycling data
Switching power on/o
Activate the electrical system by pressing
the on/o button on the battery whilst this is
in the bike, Depending on the model of bike,
this button may not be accessible. If that is
the case, there is a separate on/o button on
the bike in order to switch the system on and
o .
The screen display
(A) Battery capacity indicator
(B) Current speed
(C) Display of mode for automatic gear
shifting
(D) Display with cycling data
(E) ADJUST mode display
(F) Assistance level
(G) Walk assist
This pictogram shows when there is a switch to walk assist mode
(H) Maintenance alarm
GAZ_Snelstart Shimano Steps_21_E02_V01.indd 57
„ Viewing the screen
The items displayed on the main screen differ according to the assist bicycle.
Battery level indicator
(A)
(Refer to "Battery level indicator")
Current speed
(B)
Displays the current speed. (Refer to "Display
units")
Auto gear shifting mode display
(C)
Displayed for the auto gear shifting mode.
Traveling data display
(D)
(Refer to "Switching the traveling data display")
Names of parts
Switch unit integrated type
cycle computer
X
A
Y
Light button
Main screen
(G) (H) (A)
The operation for each button is indicated below.
(F)
Switch unit integrated type cycle computer
Increase assistance
Button-X When in walk assist mode: Disengage walk
(E)
assist mode *2
Decrease assistance
Hold down: Switch to walk assist mode *2 (E)
Button-Y
When in walk assist mode: Activate walk
assist *2
(F)
Button-A Switching traveling data display
*1
Only enabled when the assist bicycle supports automatic gear shifting.
(G)
*2
Depending on the region of use, you may not be able to use it due to the la
and pushing the bicycle easy (walk assist)" for details on walk assist mode.
(H)
EN
3-type switch
2-type switch
switch unit (righ
(B)
(C)
(D)
Button-X
ADJUST mode display
Button-Y
(Refer to "NOTICE" below)
Assist gauge
Displays the current assist mode. A mode t
Button-A*1
provides stronger assistance the longer th
length of the displayed gauge.
Walk assist*1
This icon is displayed when switched to wa
assist mode.
Maintenance alert
5
Indicates that maintenance is required. Co
your place of purchase or a distributor if t
icon is displayed.
