UNITS INSTALLATION
2
2.1. UNIT INSTALLATION
2.1.1. FACTORY-SUPPLIED ACCESSORIES
Accessory
Quantity
Paper Pattern
(Carton Board)
Level Scaler
(Take out of
Paper Pattern)
Cross Recessed
Head
Screws(M6)
Flat Washer
Wire Clamp
Insulation
(26IDx100mm)
Insulation
(28IDx85mm)
Cord Band
Packing
(5Tx50x200)
2.1.2. INITIAL CHECK
Install the indoor unit with a proper clearance around it
-
paying careful attention of installation direction for the
piping, wiring and maintenance working space, as shown
below.
Provide a service access door near the unit piping
-
connection area on the ceiling.
Service Access Panel
Piping
connection
Purpose
For Adjusting
1
Space of False
Ceiling Opening
and Position of the
1
Unit
For Fitting Paper
6
Pattern
For Unit
8
Suspension
For Drain Hose
1
Connection
1
For Refrigerant
Piping Connection
1
For Fixing Remote
Control Switch
8
wiring and
Insulation of Piping
For Covering Wiring
1
Connection
Suspension
Service Access Panel
Piping
Connection
Check space between ceiling and false ceiling is enough
-
as indicated below.
Check the ceiling surface is flat for the air panel
-
installation work.
Indoor
unit
Check down slope Pitch of Drain Piping is following the
-
specifications indicated in chapter Drain Piping.
2.1.3. OPENING OF FALSE CEILING
Cut out the area for the indoor unit in the false ceiling and
-
install suspension bolts, as shown below :
A (Opening)
B (Suspension)
Wireless Receiver,
Panel
with Wireless Receiver Type
Model
RCD-1.0
RCD-1.5
RCD-2.0
RCD-2.5
RCD-3.0
RCD-4.0
RCD-5.0
Check to ensure that the ceiling is horizontally level,
-
otherwise water can not flow.
Strengthen the opening parts of the false ceiling.
-
Air Panel (Option)
Piping
Piping
A (mm)
B (mm)
1060
890
1620
1450
