Tectro T8000 Manuel D'utilisation page 56

• Using the round window connectors
1
Dig a hole (diameter > 112mm) on the wall/glass to fit the supplied round window connector.
2
Take off the adaptor
round window connector.
3 When the hole is not in use. Use the cap
Mounting of the exhaust pipe
1
The supplied exhaust hose can be extended from 300 to 1500 mm for mounting. It is recommended that
you use the hose in the shortest possible length.
2
Take care to prevent any bow or bend in the middle of the exhaust hose, as this will trap hot exhaust
air, which will radiate into the room and cause this unit to shut itself off due to overheating.
WARNING!
The length of the exhaust pipe is specially
designed according to the specification of
this product. Do not replace or prolong it
with your own private hose as this could
cause the unit to mal-function.
4
56
(the one which does not connect with the unit), fit the hose directly to the
for the round window connector to cover the hole.
Round window
connector
