Description and function
6
Description and function
The CIF modules expand the device with communication interfaces of various stand-
ards.
More information at www.wilo.com/automation.
7
Installation and electrical connection
Electrical connection may only be carried out by a qualified electrician and in accord-
ance with the applicable regulations!
WARNING
Personal injury!
• Adhere to existing accident prevention regulations.
DANGER
Risk of fatal electrical shock!
• Exclude risks from electrical current.
• Local directives or general directives [e.g. IEC, VDE, etc.] and instructions from
local energy supply companies must be adhered to.
7.1
Installation
The installation of the CIF modules is described in the installation and operating in-
structions of the product into which the CIF module is to be installed.
To ensure interference resistance in industrial environments (EN 61000-6-2), the
data cables must be shielded cables and they must be used with an EMC-compliant
cable gland (included with the module).
The screen must be earthed at both ends.
For optimal transmission with BACnet MS/TP, CANopen or Modbus RTU, the data
cable pair must be twisted and have a surge impedance of 120 Ω.
DANGER
Risk of fatal electrical shock!
Before all work deactivate power supply and guard against accidental switch-on.
Work on the control module may only be started after 5 minutes have elapsed,
due to the dangerous residual contact voltage.
Check whether all connections (including potential-free contacts) are voltage-
free.
9
WILO SE 2018-05
