Product information
Technical data
CAN interface as per ISO 11898-2
Line length
Termination resistor
RS485 interface as per EIA/TIA (RS) 485-A
*
Load (unit load)
Input voltage
Termination resistor
TP/FT-10 interface
Line type
Line length
PLR interface
Interface
Line length
Table 3: Technical data
5.3
Standards
The BACnet CIF modules correspond to ISO 16484-5:2016 (protocol revision 4). De-
tails can be found in the PICS Statement.
The CANopen CIF modules correspond to the following CAN in Automation standards:
▪ CiA 301 Version 4.2.0: CANopen application layer and communication profile
The LON CIF modules correspond to the following Lonmark standards:
▪ Application Layer Interoperability Guidelines Version 3.2
▪ Layers 1-6 Interoperability Guidelines Version 3.2
▪ node object 0000_20
▪ pump controller object 8120_10
▪ Resource Files Version 13.00
In RTU mode, the Modbus RTU CIF modules correspond to the MODBUS APPLICATION
PROTOCOL SPECIFICATION V1.1 and Modbus over Serial Line protocol V1.02, avail-
able at modbus.org.
Installation and operating instructions Wilo-CIF-Module
200 m (max.)
120 Ω (integrated, switchable)
1/8 unit load
Max. 12 V (differential A-B)
120 Ω (integrated, switchable)
J-Y(St) Y 1 x 2 x 0,8 mm / CAT 5 AWG 22
900 m for bus topology (with termination res-
istor) and spur lines with a max. length of 3 m or
450 m for free topology, no more than 250 m
between 2 inter-communicating nodes
Current loops (≅ 5 mA)
²
200 m (max. / 0.5 mm
)
