Technical data

General data

Area
Order designation
Communication medium
Network topology
Number of bus nodes
Distance between two bus
nodes
INTERBUS identification
(ID code)
Drive profile
INTERBUS node
Baud rate
Process data words (PCD),
16 bits
Parameter data words (PCP),
16 bits
PDU length
Supported PCP services
Communication time
EDK82ZAFIC−010 DE/EN/FR 6.0
Values
E82ZAFIC010
RS485
Ring (go and return line in the same cable)
Dependent on INTERBUS master (e.g. Phoenix Contact G4 master).
For the following data, which depend on whether PCP
communication is used or not, always the smaller value applies:
l
with PCP communication: max. 62 or
l
without PCP communication: max. 256/number of PCDs
Max. 400 m
l
With 1 word PCP: 227 (0xE3)
l
Without PCP: 3 (0x03)
DRIVECOM profile "Drive technology 20"
Slave
500 kbps
1 ... 4 words
0 or 1 word
Max. 64 bytes
l
Initiate
l
Abort
l
Status
l
Identify
l
Get−0V−long
l
Read
l
Write
l
Sum of the cycle time and the processing time in the bus nodes.
The times are independent of each other.
l
Processing time in the standard device
– Parameter data (PCP): approx. 30 ms + 20 ms tolerance
– Process data (PCD): approx. 3 ms + 2 ms tolerance
l
