Product Overview; Assembly & Operations - Vileda JetClean 0677-01 Mode D'emploi

G
see page 3 of this instruction manual.
1. Handle
2. Power ON / OFF
3. Clean water tank
4. Main unit
5. Dirt water tank
6. 2in1-Filter
7. Microfiber roller
see page 2 of this instruction manual.
1 2
Remove protecting elements including carton in the bottom of the nozzle. Insert the handle into body of
main unit until you hear a click.
Place the appliance on its nozzle in the upright park positon.
3
Fill the water cup with tap water, optionally with a drop of non-foaming floor cleaner detergent. Important: Fill
with cold water or hand warm tap water (max. 40° C). Do not under any circumstances add hot or boiling water.
4
Open the clean water tank cap and fill with water.
•
The clean water tank might still be wet inside after production tests.
•
Do not overfill the tank, watch out for the MAX level sign!
5
Unwrap the power cord from the cord hooks and plug into main power socket. To facilitate the cleaning, the
cord can be positioned in the cord holder.
Press the power ON button above the clean water tank to switch on the appliance.
6
Recline the body of the appliance by placing your foot gently on the nozzle and tilting the handle backward.
7
To activate wet mopping, press the clean water spray switch on the handle grip. LED lights will turn on when
water is being distributed. Press a second time to stop the water distribution.
•
It is possible to control manually the amount of water which is being released and, thus, to cover bigger
surface with one filling of the clean water tank. Simply pause water release by pressing the blue button on the
handle. It can be reactivated any time.
8
Clean and vacuum in a forward-backward movement over the same area to remove excess water from the
floor. > Forward movement: the suction mouth in the front picks up dust and all kinds of particles; the rotating
microfiber roller mops the floors with clean water. > Backward movement: the rotating microfiber roller mops
a second time and the suction mouth sucks up excess dirty water from the floor, leaving the floor clean and
dry.
9
When finished cleaning, turn power OFF and disconnect plug from electric main power socket before
emptying the dirt water tank.
•
Do not remove the plug by pulling the cable.
10
Take the dirt water tank out from the main unit.
11
Open the dirt water tank by pressing the red opening buttons on the front and back of the dirt water tank and
with your other free hand, carefully remove the upper tank cover.
12 Empty out the contents of the dirt water tank, rinse out with clean water until clean, then set aside to dry.
13
For further maintenance or troubleshooting please read the instruction manual.
Cord
see page 5 of this instruction manual.
1
Wrap the cord around the quick release cord hook and the lower cord hook.
10

2. PRODUCT OVERVIEW

3. ASSEMBLY & OPERATIONS
8. Nozzle cover
9. Spray indicator LEDs
10. Clean water spray switch
11. Quick release cord hooks
12. Plug
13. Easy clean storage tray
14. Water cup
