Technical data KFA-5-2...

Technical data
Electrical version
Output
Type NPN
Connection diagram no.
Type PNP
Connection diagram no.
Type AC
Connection diagram no.
Operating voltage (U
Output current max. (I
Permitted ripple max.
No-load current (I )
o
Power consumption
Permitted ambient temperature
LED-Display
Protective circuit
Norm
Degree of protection IEC 60529
Connection cable
BE connection cable
Certificates
Connection diagram:
1
2
Transistor output / antivalent
)
B
)
e
Green: U
yellow: operating state
2 m, PVC 4 x 0,14 mm²
0,5 m, 1 x 0,75 mm²
CE, RoHS, UL-CSA
Connection diagram 3
Relay output
24 V DC
KFA-...-2-N-A-Y...
1
KFA-...-2-P-A-Y...
2
-
-
18...36 V DC
2 x 250 mA
40 %
Typ. 50 mA
-
-25...+55 °C
stand by /
B
Built-in
EN 60947-5-2
IP 54
Dimension:
115/230 V AC / 50/60 Hz
2 x change-over contact
-
-
-
-
KFA-...-2-L-II-Y...
3
105...125/207...253 V AC 50/60 Hz
-
-
-
Typ. 3 VA
-25...+55 °C
Green: U stand by /
B
yellow: operating state
Built-in
EN 60947-5-2
IP 54
2 m, PUR 8 x 0,25 mm²
2 m, 1 x 0,75 mm²
CE, RoHS
