Aquatec R / F / XL
A
7. Release the rear suction cup A by pulling up on its tab B.
8. Lift the rear of the seat further. This releases the front suction
cups.
IMPORTANT!
– If the height adapters have been installed
(optional), you also have to pull the tabs of the
front suction cups to release them.
9. Lift the seat out of the bathtub.
10. Carefully store all components of the bath lift.

4.4 Charging the battery

The bath lift cannot be used when the battery is charging.
WARNING!
Risk of electric shock
– Only recharge the battery in dry rooms and never in
the bathroom.
12
IMPORTANT!
– Only use the charger supplied (Aquatec® R / F / XL)
to charge the battery in the hand control.
– Only connect the charger to the mains when the hand
control is connected to the charger.
– Make sure that the voltage specifications shown on the
charger correspond to those of the mains supply.
A
G
D
F
E
1. Insert the jack plug F of the charger C into the jack socket E
on the spiral cable D of the hand control A until it engages.
2. Insert the mains plug B of the charger into a power socket.
The red indicator lamp G on the hand control extinguishes
when the battery is completely charged. It is not possible
to „overcharge" the battery.
3. Disconnect the charger from the power socket.
4. Pull the jack plug of the charger out of the jack socket of the
hand control.
B
C
1471194-A
