14
Front USB Input 5
See Figure 7
The front USB input can be connected to an iPhone, iPad or iPod device
providing music playback. Simply plug the device into the front USB and
select USB function from the source selector. The iPod and iPhone remain
active allowing search and play functions.
APTX Bluetooth Connection [
[
The Bluetooth Antenna on the RC-1572's back panel is for wireless
streaming via Bluetooth from your device (i.e. mobile phones, tablets or
computers). From your device, look for "Rotel Bluetooth" and connect to it.
Connection is normally automatic, but if prompted for a password, please
enter "0000" on your device. The RC-1572's supports both traditional
Bluetooth and APTX Bluetooth audio streaming.
Rear USB Power Port q
The rear USB port provides 5V/0.5 amps for charging or powering
USB devices including streaming music players. This port does not allow
playback of audio.
The port can be configured to remain powered even when the RC-1572
is in standby mode through the front panel setup menu (See USB POWER
option on page 16).
This configuration option allows the attached streaming source to remain
powered for use with the Signal Sense function for automatic power on/
off control of the amplifier.
NOTE: When configured to provide continuous power to the rear panel
USB port the RC-1572 will consume additional power even when in
standby mode.
Audio Controls
Volume Control 4 G
Turn the controls clockwise to increase the volume, or counter clockwise to
decrease the volume. From the remote control press the volume + or - button
to turn the volume up or down. Press the MUTE
mute the volume.
Balance Control 8 C
The Balance Control adjusts the left-to-right balance of the sound output. The
factory default is the center position or "0". To change the balance from
the front panel, press the MENU
BALANCE setting mode. Then press the - or + buttons on the front panel to
change the value to LEFT or RIGHT. The value can change from L15 to R15.
NOTE: This setting is saved permanently including after powering off
the RC-1572.
To make temporary changes not saved after power off, from the remote
C
control press the BAL button to access the BALANCE setting menu, then
E
press the up/down/left/right
H
button to completely
button to toggle the front display to
8
arrow buttons to adjust.
Tone Control Bypass 8 C
Bass and Treble Control (Tone Control) circuits are bypassed at factory
default to ensure the purest possible sound. To turn on the tone control from
the front panel, press the MENU
then press the - or + buttons on the front panel to turn bypass on or off.
When tone bypass is set to on, the front display will show TONE BYPASS.
NOTE: This setting is saved permanently including after powering off
the RC-1572.
To temporarily changes the Tone Control Bypass, press the BYPASS
on the remote control to toggle the Bypass mode enabled and disabled.
Bass and Treble Controls 8C
To set the Bass or Treble controls from the front panel , press the MENU
button to toggle to the Tone control menu and press the ENTER
to toggle to either the BASS or TREB Setting menu. Then press the - or +
button on the front panel to adjust the value. The Bass and Treble values
range from -10 to +10.
NOTE: These settings are saved permanently including after powering
off the RC-1572.
To temporarily change the Bass and Treble settings from the remote control,
C
press the BASS or TREB button, then press the up/down/left/right
arrow buttons on the remote control to adjust the value.
NOTE: Bass and Treble changes are only available when Tone Bypass
is disabled (see Tone Control Bypass section).
A properly setup high-performance audio system produces the most natural
sound with little or no adjustment of the tone controls. Use these controls
sparingly. Be particularly careful when turning the controls up as this
increases the power output in the bass or treble range, increasing the load
on the amplifier and speakers.
NOTE: Setting the Bass and Treble controls do not automatically turn
on the tone control. To turn on tone control, refer to previous section
Tone Control Bypass.
Source Input Selector 7 K
Press the corresponding input button on the front panel
K
to select the desired listening source.
Push the front panel source buttons to toggle between Optical 1 - 2 and
Coaxial 1- 2 or use the dedicated source button on the remote control.
Dimmer Control
Display Dimmer 8 B
To change the brightness of the front display, press the MENU
to toggle to the DIMMER Setting. Then press the - or + buttons on the front
panel to change the display brightness.
NOTE: This setting is saved permanently including after powering off
the RC-1572.
To temporarily change the display brightness, press the DIM
the remote control.
RC‑1572 Stereo Control Amplifier
button to toggle to the Bypass control
8
7
or remote control
B
C
button
8
button
8
E
8 button
button on
