INFOSEC UPS SYSTEM E6 LCD RT 5000 Manuel Utilisateur page 44

5000VA model
6/8000VA model
6. External battery bank
E6 LCD RT 5000: The batteries are fitted inside UPS bank.
For all other UPS from 6000 to 10kVA, the batteries are fitted inside an external battery bank.
Please refer to the battery bank user's manual for a correct procedure.
Refer to the following chart for external battery bank connection.
INFOSEC UPS SYSTEM – 4 rue de la Rigotière – 44700 Orvault – France – www.infosec-ups.com
43
Hot Line Tel : +33 (0)2 40 76 15 82 – fax : +33(0)2 40 94 29 51 – hotline@infosec.fr – 11 11 AA 68 203 16
Model Maximum Current
6KVA
8KVA
10KVA
10KVA model
Conductor Section
25A
33A
41A
6 mm²
6 mm²
6 mm²
