• Do not position the heater at an angle of more than 50°from the rear wall
(See Fig 2).
5
Fig 1
Installation
1. Securely fasten the bracket to the
mounting surface using the fixing
in the bracket (See Fig 3).
2. Fix in the required angular position
by tightening the fixing bolt on the
bracket at the rear of the heater.
3. The bracket can be used to adjust
the direction of the heater up and
down (See Fig 4).
This is done by loosening the bolts fixing the heater to the bracket, and
then retightening once the correct position is achieved.
Always isolate the heater from the mains supply when adjusting the angular
position.
• Disconnect from the mains before commencing any maintenance procedure
including cleaning.
• To ensure optimum heat effectiveness, it is rec-
ommended that after the heater has been used
for approximately 80-100 hours, that the guard
and lamp are removed and the reflector is wiped
with a lint-free cloth before reassembling.
• If the supply cord becomes damaged, it must be
replaced by the manufacturer, its service agent or a qualified person.
Fig 2
Fig 3
Fig 4
