Before Calling for Service

Before calling for service, check the following to avoid
unnecessary service charges.
Be sure to check these items first:
• Is there a power outage in the area?
• Is the household circuit breaker tripped?
• Is the range disconnected from the electrical supply?
If the Burners do not Ignite
• Are the burner caps properly aligned and seated in the
burner bases?
• Are the burner ports clogged?
• Is the circuit breaker tripped?
• Is the manual shut-off valve closed, preventing the flow
of gas?

Data Rating Plate

The data rating plate shows the model and serial number of
your range. It is located under the front edge of the range's
cooktop, and is visible when the oven door is open (see
illustration).
Data rating plate(s) located
under front edge of
cooktop.
Wiring diagrams
placed behind toe
kick panel.
Figure 34: Rating Plate and Wiring Diagram Locations (oven
English 38
The electric wiring diagrams and schematics in the toe kick
area should not be removed except by a service technician.
Replace after service.
Before removing the toe kick panel, disconnect the
range from the electrical power supply. Reinstall the toe
kick panel before reconnecting the range to the power
supply and operating the range.

Service Information

For handy reference, copy the information below from the
data rating plate. Keep your invoice for Warranty validation.
Model Number __________________________________
Serial Number ___________________________________
Date of Purchase ________________________________
Dealer's Name __________________________________
Dealer's Phone Number ___________________________
Service Center's Name ____________________________
Service Center's Phone Number ____________________
Also, enter this information on the Product Registration
Form included with this product, then mail it to the indicated
address.
door not shown)
CAUTION:
