CONTENTS OF KIT IM-4
Icemaker
1
Owner's Manual &
2
Installation Instructions
3 Water Valve and
Tube Assembly
Adhesive-Backed Water Tube
4
Fasteners, to secure plastic
water tube (4)
Hex-Head Screw
5
for Water Line Clamp
Installation Instructions
Water Line Clamp
6
(strain relief), for
house water line
ICEMAKER
WARRANTY VERIFICATION
Date Installed
Dealer
Warranty Label
7
Fill Tube Extension
8
(3/4" O.D.)
Ice Bucket
9
Hex-Head Screw, for
10
attaching water valve
11 Phillips Head Screws,
for mounting icemaker (2)
8
12 Water Tube Inlet
Fill Tube
13
(5/8" O.D.)
Fill Tube with Foil
14
(5/8" O.D.)
Icemaker Fill Cup
15
(side-mounted)
16 Hose Clamp
Water Tube
17
Inlet Cover
Hex-Head Screws, for
18
attaching water tube
inlet cover
