Safety Information
Operating Instructions
Before You Call For Service . . . . 3-5
Normal Sounds You May Hear . . . . 2
Preparing for Vacation . . . . . . . . . . 2
When You Should Set the
Feeler Arm to OFF . . . . . . . . . . . . . . . 2
Installation Instructions
Icemaker . . . . . . . . . . . . . . . . . . . . . 8, 9
Water Line . . . . . . . . . . . . . . . . . . . . . 10
Parts List . . . . . . . . . . . . . . . . . . . . . . . . 7
Consumer Support
Consumer Support . . . . . Back Page
Warranty . . . . . . . . . . . . . . . . . . . . . 11
SAFETY PRECAUTIONS
FOR YOUR SAFETY:
Do not place fingers or hands in the automatic
icemaking mechanism while the refrigerator
is plugged in. This will help protect you from
possible injury.
READ AND FOLLOW THIS SAFETY INFORMATION CAREFULLY.
READ AND SAVE THESE INSTRUCTIONS
GEAppliances.com
. . . . . . . . . 1
. . . . . 2
. . 6-10
It will also prevent interference with moving
parts of the ejector mechanism and the heating
element that releases the cubes, located on the
bottom of the icemaker.
162D4614P015
Owner's Manual and
Installation Instructions
Machine à glaçons
Manuel d'utilisation
et d'installation
La section française commence à la page 19
Equipo de Accesorios
Máquina de Hielos
Manual del propietario
e instalación
La sección en español empieza en la página 37
49-60684 05-13 GE
Trousse
