The value indicated becomes higher or lower as the laser
beam is moved.
1. Press the laser beam UP or DOWN button. The laser
beam then moves up or down.
en
7.7 Beam position indicator 7
Beam position indicator
@
End position left
;
End position right
=
7.8 Adjusting the position of the beam 7
The maximum lateral adjustment range is 9m at a distance
of 30m. The speed of movement can be varied.
If the button is pressed briefly, the laser beam moves
slowly.
If the button is pressed for longer, the laser beam moves
quickly.
The current position of the beam can be read from the
display at any time.
7.8.1 Adjusting the beam end position left / right
The display informs the operator when the beam has
reached the left or right end position and cannot be
moved further. The display blinks to inform the operator
of this status.
7.11 Display while searching 8
The laser tool is not yet ready
for automatic alignment.
@
The display indicates stabiliz-
ation of the laser beam after
;
self-leveling.
The display indicates that
searching (auto centering)
=
is in progress.
Automatic alignment has
been completed.
%
Error during automatic align-
ment.
&
7.12 Selecting the laser beam mode
Press the laser beam mode button as often as necessary
until the desired display mode is shown in the display.
Constant beam
Blinking beam
High-power mode (only with the PP 11)
20
2. Press the laser beam UP and DOWN buttons at
the same time to move the laser beam to the zero
position.
The laser beam moves immediately to the 0.000%
position.
7.6 Aligning the target line 7
Use the direction control buttons on the PP 10/11 or PPA
20 remote control unit to move the laser beam horizontally
to the right or left.
Shows the direction of the laser beam relative to the tool.
Shows that the laser beam cannot be aimed further to the left.
Shows that the laser beam cannot be aimed further to the right.
If this position is reached frequently it is recommended
that the tool is pivoted slightly to the left or right and the
beam then realigned.
7.9 Automatic centering
Press the two direction control buttons (left and right) at
the same time.
The laser beam returns to the center automatically.
7.10 Automatic alignment with the target plate 8
1. Set up the target plate with the reflective stripes
facing the laser tool.
2. Press the target plate auto-centering button.
NOTE This function may take up to 2 minutes before
starting.
The tool then searches for the target plate within its
alignment range (left/right).
The tool has not yet completed the self-leveling procedure.
NOTE This procedure will first be completed.
Please wait until this operation has been completed.
Searching (auto centering) then begins.
Check the position of the laser spot on the target plate.
NOTE If necessary, the remote control or the direction control buttons on
the tool (left / right) can be used to readjust the position of the beam.
If the beam loses contact with the target plate while searching, the pro-
cedure must be restarted.
7.13 Adjusting the electronic bubble level 9
When the tool is pivoted, the bubble level appears clearly
in the display.
Adjust the tool until the "bubble" is in the center of the
display.
