POSSIBLE TROUBLESHOOTING
7) Signalling: smoke °C/high.: (turns off due to exceeding maximum smoke temperature).
Problem: Switching off due to exceeding the maximum smoke temperature.
Check (only by the Dealer):
• pellet type, anomaly in smoke extraction,
• smoke channel blocked,
• incorrect installation,
• gear motor 'drift'
8) Signalling: Check button (signals an anomaly on the emergency button)
Actions: • check maintenance status of the button and its board connection cable (DEALER).
9) Signalling: Veri c./air ow: (intervenes if the ow sensor detects insuf cient combustion ).
Problem: Turns off for lack of depression
• Flow may be insuf cient if there is a hatch open or the hatch is not perfectly sealed (e.g. seal awed).
• This may also be the case if there is a problem with air intake or smoke extraction, or if the
• combustion chamber is blocked or the ow sensor dirty (clean with dry air).
• Also check that the ow sensor limits are within the parameters.
• The depression alarm may also be signalled during ignition, if the chimney ue does not comply with
• speci cations or the chimney ue and chimney pot are clogged.
10) Signalling: H2O TEMPALARM (Activated if the water sensor is faulty or disconnected)
Problem: Shuts down due to water temperature being higher than 90 °C.
An excessive temperature may occur because of the following:
• system too small: ask the DEALER to activate the ECO function
• blockage: clean the exchanger pipes, the combustion chamber and the smoke outlet.
11) Signalling: "Battery check"
Problem: The boiler-stove does not stop but the error appears on the display.
Actions: • The buffer battery of the control board needs changing (DEALER).
12) Signalling: HIGH CURRENT ALARM: Activated when anomalous, excessive current is being
absorbed by the gear motor.
Actions: Check functioning (CAT): gear motor - Electrical connections and electronic board .
13) Signalling: LOW CURRENT ALARM: Activated when anomalous, insuf cient current
absorption is detected on the gear motor.
Actions: Check functioning (CAT): gear motor - pressure switch - tank thermostat - electrical connections and
electronic board
14) Problem: Remote control not working
Actions: • Move closer to the boiler-stove
• check the battery and if necessary, replace it.
• Synchronisation with automatic search on activation: when you put the batteries into the radio control a
radio channel search phase will start up automatically, and it will subsequently connect to the product de-
tected. So that this occurs correctly, make sure to switch the product on before inserting the batteries in the
radio control, and stay in the vicinity of the antenna in order to achieve radio coverage with certainty.
• Synchronisation with automatic search and manual activation - it is possible to launch an automatic search
for a product manually, simply carry out the following operations after having already put the batteries into
the radio control:
- Approach the device and make sure that it is connected to the mains electricity.
- With the display switched off (standby) hold the 0/I key down for 10".
- After 10" a "NETWORK SEARCH" message appears on the display, then release the o/I key, as this means
that the automatic search has been activated.
- Automatic tuning of the radio channel will occur within a few seconds.
