5-Step Installa on Guide

5 STEP INSTALLATION GUIDE
Step 1. Mount the Energizer
The energizer is easy to install. Mount the energizer on a wall,
under cover, out of reach of children, adjacent to a power
outlet.
Install where there is no risk of the energizer incurring fi re or
mechanical damage.
a) Using the template on the center page as a drilling
guide, drill 2 x
b) Fix the screws provided into the wall leaving the head
of the screw about
c) Place the energizer over and slide down onto the
moun ng screws.
Step 2. Install the Ground system
Buildings and gates for example, can become electrifi ed with fence voltages if the
energizer is improperly grounded.
a)
Ground Rod Clamp
(352HD)
8
5 / " holes (A & B).
32
1
/ " out from the wall.
8
All hot wire system
(for areas with good grounding systems)
HobbyMaster
M50
Green
Ground Rod
(351)
Gallagher 3E1803 110V Energizer User Manual
The livestock must touch the wire and
the ground to feel a shock
Red
a
b
Hot
Hot
Hot
