1. Remove the (3) Torx stainless screws in the front face
of the included Zero Clearance Trim.
Figure 18: Zero Clearance Trim Front Face Screw Removal
2. Remove the (4) drill point screws securing the trim to
the side panels, and the (3) drill point screws securing
the piece to the back panel. Lift up to fully remove.
Figure 19: Zero Clearance Trim Rear Screw Removal
3. Align the back panel of the new accessory with the
flanges on the range side panels right and left rear
corners. The backguard is inserted inside the guide
channels on the back of the range.
4. Make sure the backguard's front face is outside the
flange on the front side of the range.
5. Re-install screws removed in Steps 1 and 2.
Figure 20: Backguard Installation
Figure 21: Low Back Front View
