(4)
Measuring button [ ]
(5) Colour display
(6) Reference level selection button
(7) Minus button [–]
(8)
On/off button [ ]
(9) Battery compartment cover
(10) Locking mechanism of the battery compartment cover
(11) Serial number
(12) Reception lens
(13) Laser beam output
(14) Laser warning label
(15) Laser viewing glasses
(16) Laser target plate
(17) Protective bag
A) Accessories shown or described are not included with the product as standard. You can
find the complete selection of accessories in our accessories range.
Display elements
(a) Bluetooth® status
Bluetooth® activated, no connection established
Bluetooth® activated, connection established
(b) Battery indicator
(c) Measured value
(d) Result
(e) Laser switched on
(f) Reference level of measurement
(g) Measuring function
Length measurement
Continuous measurement
Area measurement
Volume measurement
(h) Error indicator
