HMPL-...
Size
Screw size
Max. perm. screw depth
Fig. 13
Additional instructions on fitting in conjunction with Festo components are
summarized in the system manual "Handling technology."
In addition to direct fastening by means of the threaded holes 1 , the
HMPL-... can also be fastened by means of a dove-tail adapter plate as per
"Accessories."
For exact alignment during fitting
S
Use the centring rings supplied.
S
Tighten the fastening screws to the same extent.
Definition
Moving mass = work load + moving dead weight + mass of the fastening elements
S
When placing the moveable mass, make sure
that the following specifications are fulfilled:
– the permitted transverse force F
– the permitted longitudinal force F
(vertical fitting)
– the permitted torques M
– and that the module is not tilted.
The permitted values can be found in the
"Technical specifications" and in the dia-
grams in the chapter "Characteristic
curves".
S
Place the work load so that the tilting
torque (M
26
HMPL-12-...
M 5
8 mm
= M
x
= F S a) remains small.
K
HMPL-16-...
M 5
9 mm
,
Q
L
= M
y z
Fig. 14
Fig. 15
