Setting up
Setting with drum stops
The drum stops provide set spacings.
They are pre-set at 22 mm, 37 mm and 57 mm.
Pull bench back a short distance.
To make the setting, turn drum stop
required position and engage.
Interchangeable drilling unit,
Space 22 mm
6 spindles, for drilling hinge holes
Interchangeable drilling unit,
Space 37 mm
9 spindles, for drilling hole lines
Interchangeable drilling unit,
Space 57 mm
9 spindles, for drilling hole lines
Note:
This setting must be made on both sides
of the machine!
Move bench against stops
1
Carry out trial drilling.

Pendulum stops

Adjust pendulum stops to suit application.
To make adjustments, undo screw
stop along rail.
5
Re-tighten screw.
146
to the
2
and re-tighten screws in bench.
and move pendulum
4
1
4 5
