Figure 8 Sensor with SVS dimensions
1 Minimum clearance for cable
Figure 9 Standard frame dimensions
1 579.12 mm (22.8 in.) with 2¼ in. spacer; 828.04 mm (32.6 in.) with 12 in. spacer
5.1.2.1 Assemble the clamps on the frame and wall bracket
Install the clamps on the frame and wall mount bracket before installation on the wall.
14 English
