same applies for the general rules of health and
safety at work. The manufacturer will not be liable
for any changes made to the equipment nor for
any damage resulting from such changes. Even
when the equipment is used as prescribed it
is still impossible to eliminate certain residual
risk factors. The following hazards may arise in
connection with the machine's construction and
design:
•
Contact with the saw blade in the uncovered
saw zone.
•
Reaching into the running saw blade (cut
injuries).
•
Kick-back of workpieces and parts of
workpieces.
•
Saw blade fracturing.
•
Catapulting of faulty carbide tips from the saw
blade.
•
Damage to hearing if essential ear-muffs are
not used.
•
Harmful emissions of wood dust when used
in closed rooms.

4. Technical data

Motor power supply: ............................18 V
Idle speed n .............................. 3000 min
0
Carbide
saw blade: ......... ø 8.5 in. x ⅝ in. (ø 216 x 16 mm)
Number of teeth: ............................................ 40
Swiveling range: ............................ 47° / 0° / +47°
Miter cut to the left: .................................0° to 45°
Saw width at 90°: .......4.7 x 2.4 in. (120 x 60 mm)
Saw width at 45°: .........3.2 x 2.4 in. (83 x 60 mm)
Saw width at 2 x 45°
(double miter cut left): ...3.1 x 1.3 in. (80 x 34 mm)
Max. cutting height: .....................2.4 in. (60 mm)
Max. workpiece depth: .............. 4.7 in. (120 mm)
Weight: .............................. approx.17.8 lbs (8 kg)
Laser class: ...................................................... 2
Wavelength of laser: ................................ 650 nm
Laser output: .......................................... ≤ 1 mW
Protection class .......................................... III/
Minimum workpiece size: Only ever cut
workpieces which are big enough to clamp
securely with the clamping device – minimum
length 6.3 in. (160 mm)
Anl_TE_MS_18_210_Li_SPK7_USA.indb 17 Anl_TE_MS_18_210_Li_SPK7_USA.indb 17
EN
This machine is equipped with a special precision
cut saw blade (cutting width 0.07 in./1.8 mm) for
cordless crosscut saws. If you use a diff erent saw
blade with a larger cutting width, this could result
in loss of performance.
This machine is intended for use with
rechargeable batteries and chargers from the
Einhell Power-X family only. For the current
models, please refer to the product descriptions
for the articles. These are available online.
Wear ear-muff s.
The impact of noise can cause damage to
hearing.
Reduce noise generation and vibration to a
minimum!
•
Use only equipment that is in perfect
condition.
•
Maintain and clean the equipment regularly.
•
Adapt your way of working to the equipment.
•
Do not overload the equipment.
•
Have the equipment checked if necessary.
•
Switch off the equipment when not in use.
•
Wear gloves.
CAUTION!
(rpm)
-1
Residual risks
Even if you use this electric power tool in
accordance with the instructions, certain
residual risks cannot be eliminated. The
following hazards may arise in connection
with the equipment's construction and
layout:
1. Lung damage if no suitable protective dust
mask is used.
2. Damage to hearing if no suitable ear
protection is applied.
3. Health damage caused by hand-arm
vibrations if the equipment is used over a
longer period or is not properly guided and
maintained.
- 17 -
