NOTES:
In the height adjustment, in any case respect the STOP MARK on the seat post.
The notch must always be inserted in the frame tube.
Angle
In case you want to keep the saddle not completely horizontal but with the
"nose" slightly raised, you must loosen the locking placed under the saddle
and adjust the angle. Re-tighten the lock so as not to move the saddle.
Changes in the position of the saddle, even if small, can affect comfort
while pedalling. It is recommended, each time you want to make an
adjustment, to make only one change at a time and gradually until you
find the most comfortable and correct position.
On the seat post there is the notch with stop limit. Make sure that the
clamp nuts that regulate the position of the saddle are well locked.
STEP 4: Battery
a. Insert the battery into the slot located at the rear of the bicycle frame.
b. Use the supplied keys (attached to the handlebar) to lock the battery –
turn the key clockwise to secure it.
3
1
c. Locate the red power switch under the battery and set it to the ON
position to activate battery.
d. Check charging level by pressing status button.
4 leds on: 100%
3 leds on: 70 % residual charge
2 leds on: 40% residual charge
1 led (red) lit: up to 15% remaining charge (you need to recharge the
battery as soon as possible).
How to use the E-bike
Fully charge the battery before first use.
Check tire pressure regularly for best performance.

How to charge

a. Open the rubber cap and plug the charger into the e-bike charge port.
Make sure that the charger port is in the given direction.
b. Plug the charger into the mains wall socket.
c. When connected to the battery charger, the battery will start to charge
and the charge indicator on the charger will turn red.
d. After the charging is complete, the charge indicator will turn green.
Remove the battery charger when fully charged.
e. Close the rubber cap after charging.
