What's in the Box:

E-Bike Parts
• 1 × E-bike
Accessories Box
• 1 × Quick Start Guide (this document)
• 1 × Warranty guide
• 1 × Charger
• 2 × Pedal
• 2 × Battery keys
Accessories Box
(Refer to 1 on page 1)
Bike Parts
(Refer to 2 on page 1)
Bike Frame Number
The bike frame number can be found stamped on the tube, as shown in
the figure. It is the unique identifier for your e-bike. When your bike is
stolen, it's the serial number that gives you the biggest chance of getting it
back. It would be a good idea to write it somewhere or take a picture.
Assembling the E-bike
The bicycle comes assembled with turned handlebar. Turn the handlebar
referring to the dedicated paragraph. The pedals are to be assembled.
Refer to the dedicated paragraph. Remove the protections and position it
correctly to be able to use the bicycle. To remove and reposition it, refer to
the dedicated paragraph.
STEP 1: Install and adjust the handlebar
a. Turn the handlebars perpendicular to the bike, If necessary, you can
adjust the angle of the handlebars. Use a allen key to loosen screws and
adjust handlebar, after that retighten the screws.
b. Use a allen key to loosen the angle adjustment screw at the bottom of
the stem. Adjust the stem to a suitable angle and retighten the screw.
c. Adjust the position of the brake levers, display, ringbell to fit your
requirements.
CAUTION: Be sure to carefully fasten all locks before riding the bicycle.
STEP 2: Install the pedals
Use the 15 mm wrench to mount the pedals, as shown in figure.
L R
NOTES:
Pedal thread must be lubricated before being assembled.
Check the end cap on both pedals to identify the left pedal and right pedal.
Please note that the right pedal will tighten clockwise, while the left pedal will
tighten anticlockwise. Make sure the torque is about 35 N·m.
STEP 3: Saddle height adjustment and tightening
Adjust the saddle
The correct adjustment of the saddle is important for the position of the
body while pedalling and allows you to obtain the best performance with
less stress on the joints.
Before use, ride the bicycle and adjust the height and angle of the saddle.
Height
The height of the saddle must be adjusted according to the length of the
legs. The height is correct if, while sitting, you reach the pedal placed in the
lowest position with the heel. The leg must be completely straight. Adjust
the height according to these indications.
Open the closing lever and adjust the height of the saddle, after the
adjustment is done, tighten the screw or clip locking the support.
