The Fuel System:
moves through the solenoid valve and out the nozzle.
The Air System:
This air is heated and provides a stream of clean, hot air.
The Ignition System:
plug/ignitor ignites the fuel and air mixture.
The Safety Control System:
mum fresh, outside air ventila-
tion requirements. If proper
fresh, outside air ventilation is
not provided, carbon monoxide
poisoning can occur. Provide
proper fresh, outside air ventila-
tion before running heater.
Provide a fresh air opening of at least 3 ft
for each 100,000 Btu/Hr rating. Provide extra fresh
air if more heaters are being used.
derstand the warnings in the
Safety Information section, page
2. They are needed to safely op-
erate this heater. Follow all local
codes when using this heater.
4
Downloaded from www.Manualslib.com
THEORY OF OPERATION
The hose/regulator assembly attaches to the propane gas supply. The propane gas
The motor turns the fan. The fan pushes air into and around the combustion chamber.
The direct spark ignitor (DSI) sends voltage to the spark plug/ignitor. The spark
This system causes the heater to shut down if the flame goes out.
Combustion Chamber
Clean
Heated
Air Out
(Front)
Nozzle
DSI
Figure 2 - Cross Section Operational View
VENTILATION
WARNING: Follow the mini-
INSTALLATION
WARNING: Review and un-
manuals search engine
Ignitor
Fan
Solenoid
Valve
Air For Combustion
And Heating
WARNING: Test all gas piping
and connections for leaks after
installation or servicing. Never
use an open flame to check for
a leak. Apply a mixture of liquid
soap and water to all joints.
Bubbles forming show a leak.
Correct all leaks at once.
1. Provide propane supply system (see Propane
Supply, page 3).
(0.28 m )
2 2
2. Connect POL fitting on hose/regulator as-
sembly to propane tank(s). Turn POL fitting
counterclockwise into threads on tank. Tighten
firmly using wrench. Tighten regulator with vent
pointing over the hose (see Figure 3, page 5).
3. Connect hose to inlet connector. Tighten firmly
using a wrench (see Figure 4, page 5).
IMPORTANT: Extra hose or piping may be
used if needed. Install extra hose or piping
between hose/regulator assembly and propane
tank. You must use the regulator supplied with
heater.
www.desatech.com
Motor
Cool
Air In
(Back)
Power Cord
On/Off Switch
Hose/
Regulator
Fuel
Assembly
109005-01C
