MODEL RCLP155AT
This list contains replaceable parts used in your heater. When ordering parts, follow the instructions
listed under Replacement Parts on page 7 of this manual.
109005-01C
Downloaded from www.Manualslib.com
KEY
NO. PART NO. DESCRIPTION
1 098511-116 Upper Shell (Replacement Part Will Be Black)
2 M15823-27 Screw, #10-16 x 1/2"
3 ** Combustion Chamber Kit
4 099138-01 Nozzle
5 099133-01 Ignitor
6 M11084-38 Screw, #8-18 x 3/8"
7 099334-01 Fuel Tube Kit
8 097806-02 Ignitor Cable
9 098276-01 Plug 1/8 NPTF Hex
10 M51153-01 Fan
11 105336-01 Motor
12 097776-01 Universal Bushing
13 078978-01 Sleeve Cap
14 M51572-02 Male Connector
15 103015-01 Solenoid Valve
16 099161-10 Base
17 098884-03 DSI Control
18 M12461-7 Screw, #6-32 x 1"
19 099432-01 Hex Nut, #6-32
20 M11084-27 Screw, #10-16 x 1/2"
21 M50104-05 Shorty Bushing
22 M50104-01 Shorty Bushing
23 101732-01 Thermal Limit Switch
24 097968-05 Screw, #4-40 x 1/2"
25 097384-04 Hex Nut, #4-40 Captive Washer
26 098511-129 Lower Shell (Replacement Part Will Be Black)
27 098447-03 Side Cover
28 098226-01 On/Off Switch
29 097657-03 Built-in Thermostat
30 104905-01 Thermostat Knob
31 M51104-01 Handle
32 M11084-29 Screw, #10-16 x 3/4"
33 097964-03AA Fan Guard
34 101206-01 Motor & Relay Support Bracket Assembly
35 M11143-1 Strain Relief Bushing
36 098219-17 Power Cord
37 M50631 Rubber Bumper
38 NTC-4C Lock Nut
39 099157-01 Break Mandrell Rivet, 3/16"
40 099125-01 Terminal Board
41 M12461-25 Screw, #10-32 x 1/4"
42 M10908-1 Screw Hex TPG "F" 6-32 x .25
43 M11271-8 Clip Nut
44 101480-10 High Temperature Wire Assembly
45 101480-11 High Temperature Wire Assembly
46 110287-01 DSI Control No. 2003-45
47 110267-01 DSI Wire Harness (2003-45 Only)
PARTS AVAILABLE—NOT SHOWN
079663-01 LP Warning Decal (English)
079663-02 LP Warning Decal (French)
099164-04 Wiring Decal
100176-02 Warning Decal
100865-03 Operation Decal
109111-03 Tradename Decal, Reddy
111632-09 Model Decal
103021-3 Thermostat Decal
LPA3070 Regulator & Hose Assembly
LPA4020 Fuel Gas Connector
M9900170 Wire Assembly (2003-45 Only)
** Not a field replaceable part.
