Hitachi C 7BMR Mode D'emploi page 9

c) Lower guard should be retracted manually only for
special cuts such as "plunge cuts" and "compound
cuts". Raise lower guard by retracting handle and as
soon as blade enters the material, the lower guard
must be released.
For all other sawing, the lower guard should operate
automatically.
d) Always observe that the lower guard is covering the
blade before placing saw down on bench or floor.
An unprotected, coasting blade will cause the saw to
walk backwards, cutting whatever is in its path.
Be aware of the time it takes for the blade to stop
after switch is released.
PRECAUTIONS ON USING CIRCULAR SAW
1. Do not use saw blades which are deformed or
cracked.
2. Do not use saw blades made of high speed steel.
3. Do not use saw blades which do not comply with
the characteristics specified in these instructions.
4. Do not stop the saw blades by lateral pressure
on the disc.
5. Always keep the saw blades sharp.
6. Ensure that the lower guard moves smoothly and
freely.
SPECIFICATIONS
Voltage (by areas)*
Cutting Depth
Power Input*
No-Load Speed
Weight (without cord)
* Be sure to check the nameplate on product as it is subject to change by areas.
STANDARD ACCESSORIES
(1) Saw Blade (Dia. 185 mm) (mounted on tool ) ..... 1
(2) Box wrench ............................................................... 1
(3) Guide .......................................................................... 1
(4) Wing-bolt ................................................................... 1
(5) Lever (short type) ..................................................... 1
(6) Dust collector ............................................................ 1
(7) Machine screw M4 × 12 .......................................... 1
Standard accessories are subject to change without notice.
OPTIONAL ACCESSORIES (sold separately)
Washer (A)
............... for 20 mm (Hole dia. of saw blade)
............... for 30 mm (Hole dia. of saw blade)
Optional accessories are subject to change without notice.
APPLICATION
Cutting various types of wood.
90°
45°
7. Never use the circular saw with its lower guard
fixed in the open position.
8. Ensure that the retraction mechanism of the guard
system operates correctly.
9. Never operate the circular saw with the saw blade
turned upward or to the side.
10. Ensure that the material is free of foreign matters
such as nails.
11. For model C7BMR, the saw blades range should
be from 180 mm to 185 mm.
12. For model C7BMR, be careful of brake kickback.
Model C7BMR features an electric brake that
functions when the switch is released. As there
is some kickback when the brake functions, be
sure to hold the main body securely.
13. Sparks can sometimes appear caused by braking
operation when the switch is turned off since
model C7BMR employs electric brakes. Be
informed, however, that this phenomenon is not
a machine trouble.
14. For model C7BMR, when the brake becomes
ineffective, replace the carbon brushes with new
ones.
15. Disconnect the plug from the receptacle before
carrying out any adjustment, servicing or
maintenance.
(110 V, 230 V, 240 V)
60 mm
47 mm
1610 W / 1600 W
–1
5800 min
4.8 kg
PRIOR TO OPERATION
1. Power source
Ensure that the power source to be utilized con-
forms to the power requirements specified on the
product nameplate.
2. Power switch
Ensure that the power switch is in the OFF position.
If the plug is connected to a receptacle while the
power switch is in the ON position, the power tool
will start operating immediately, which could cause
a serious accident.
3. Extension cord
When the work area is removed from the power
source, use an extension cord of sufficient thickness
and rated capacity. The extension cord should be
kept as short as practicable.
4. Prepare a wooden workbench (Fig. 1)
Since the saw blade will extend beyond the lower
surface of the lumber, place the lumber on a
workbench when cutting. If a square block is utilized
as a workbench, select level ground to ensure it
is properly stabilized. An unstable workbench will
result in hazardous operation.
English
8
