SYMBOLS
Read the instructions.
Approved in accordance with
the relevant directives.
Recycle discarded product
in accordance with local
regulations.

TECHNICAL DATA

Electrical data
Amperage
Duty factor
Control engineering
Air pressure
Cutting capacity
Lighting
Protection rating
Weight
Cord length
DESCRIPTION
Compressor powered (minimum 130 l/min, 5
bar) plasma cutter with non-gas cutting. Ideal
for curved or angled workpieces of electrically
conductive material. Fitted with variable
cutting power control, handle, air pressure
control and outlets for earth cable and burner/
cutter. Accessories included: Burner and
cutter cable set (2.5 m), earth cable (2 m), air
pressure regulator with pressure gauge, two
electrodes, of which one is installed and one is
replaceable.
Keep the burner nozzle in light contact with the
workpiece when cutting. Only move the burner
in one direction, never back and forward.
Parts
1. Potentiometer (to adjust amperage from
15 to 40 A)
230 V, 50/60 Hz
15–40 A
20%
IGBT inverter
4–5 bar
12 mm in steel
Contact lighting
IP215
7 kg
2 m
2. Connection for burner
3. Connection for earth cable
4. Red status light, overheating
5. Yellow status light, cutting
6. Green status light, voltage indicator
FIG. 1
7. Pressure regulator
8. Pressure gauge
FIG. 2
Burner
1. Safety cap
2. Nozzle
3. Diffuser
4. Electrode
5. Burner
6. Burner handle
7. Trigger
ASSSEMBLY
1. The air regulator is placed inside the
product. On the air regulator there is
a male quick-coupling. Connect the
compressed air hose to the quick-
coupling. Adjust the compressor to an air
pressure of 4 to 5 bar.
2. The flow of air can be adjusted with the
knob on the pressure regulator when in
use.

HOW TO USE

WARNING!
Avoid accidental starting.
Put the switch in the off position and pull out
the plug before adjustment, maintenance
and/or changing accessories.
EN
41
