Adjustment philosophy KFW-51...ETW (1 Switching Point)
ETW
H
L

LED indication

ON
OFF
The mode changes according to the shown infinite time loop.
The mode change can be activated with the grey ETW wire.
The adjustment is made by release of the grey ETW wire from the supply voltage (+) at the desired menu
point „S1", „Reset" or „Test Function". All adjustments are initiated by disconnecting the grey wire.
HIGH level: U , LOW level: 0 V
B
The LED display is an adjustment help with its flashing sequences for each menu point.
The ETW input is inactive during initialization and adjustment.
28
S1
T 3s
0
f = 1.5Hz
f = 1,5Hz
3s
RESET
8s 13s
Double
f = 3Hz
pulses
13s
8s
Test
Function
t
f = 0.4Hz
f = 0,4Hz
t
