LC display
Installation and operating instructions Wilo-Stratos /-D/-Z
Setting
The currently set control mode flashes.
By turning the contro button other
control modes can be selected. The new
selected control mode flashes.
Pressing the button stores the new
control mode and switches to the next
menu.
Menu point only appears if a Stratos IF module
was inserted with input 0...10 V.
Switch input 0...10 V on/off
Activate input 0...10 V: "ON" and the "module
motor symbol" appears in the display.
The setting can be altered by turning
the control button.
Deactivate input 0...10 V: "OFF" appears in the
display and the "motor symbol" disappears.
Setting stored.
If the input was switched on, the menu manager
jumps to menu point .
