2
Confirm installation sizes
Installation place
The distance between the mounted indoor unit should meet the specifications illlustrated in the
following diagram.
1) Ceiling-mounted
Strong and durable ceiling
Indoor unit
Left
side
>90.6in(230cm)
>7.9in(20cm)
2) Wall-mounted
Maintenance space
>11.8in(30cm)
Floor
Floor
23.6~70.9in (60~180cm)
Air outlet
≥7.9in(20cm)
Air inlet
>0.8in(2cm)
B
Right
side
>0.8in(2cm)
Service access
≥11.8in(30cm)
31.5inx31.5in (80cmx80cm)
checking orifice
17
>11.8in(30cm)
Ceiling
Floor
