3
Hang indoor unit
3.1 Please refer to the following diagrams to locate the four positioning screw bolt
holes on the ceiling. Be sure to mark the paces where you will drill ceiling hook
holes.
Air outlet dimensions
Air inlet dimensions
MODEL
9K/12K
18K/24K
36K/48K
55K/60K
A
E
G
OUTLINE DEMENSION
A
B
C
27.6/700
9.6/245
29.5/750
39.4/1000
9.6/245
29.5/750
47.2/1200
11.8/300
29.5/750
55.1/1400
14.9/380
31.5/800
AIR OUTLET
OPENING SIZE
D
E
F
31.3/795
20.7/527
7.0/178
31.3/795
32.6/827
7.0/178
31.3/795
40.4/1027
9.2/233
33.3/845
48.1/1223
12.6/320
18
D
C
I
(unit: inch/mm)
AIR RETURN
SIZE OF
OPENING SIZE
MOUNTED LUG
G
H
I
23.3/592
8.3/212
29.1/740
35.1/892
8.3/212
40.9/1040
43.0/1092
10.5/267
48.8/1240
50.1/1272
13.0/330
56.7/1440
J
25.2/640
25.2/640
25.2/640
26.3/668
