Polaris
FREEDOM
SC Cordless Robotic Cleaner | Owner's Manual
®
™
Section 3. General Cleaner Operation
CAUTION
To prevent damage to the cleaner, be sure to adhere to the
following guidelines:
• Remove the cleaner from the pool after the cleaning cycle
is completed.
• Store out of direct sunlight or inclement weather.
• For retrieval, pickup at waterline when notified by app,
use the manual retrieval hook, or tap cleaner lid to
activate Tap & Lift
.
™
• Take additional care when lifting the cleaner out of the
pool. It becomes heavier when filled with water.
• Always remove the cleaner from pool when super
chlorinating or adding acid.
• Do not handle cleaner while it is in operation.
• Ensure that the cleaner is not in running mode before
handling.
WARNING
DO NOT use an extension cord with the cleaner
• Follow all charging instructions and do not charge outside
of the temperature range specified in the instructions.
Charging improperly or at temperatures outside of the
specified range may damage the battery and increase
the risk of fire.
• When charging, cleaner must NOT be exposed to direct
sunlight, rain or inclement weather, heat ignition sources,
pool and spa chemicals or water. DO NOT position
cleaner on direct contact with soil.
3.1
Set Up and Charging
1. Select a charging location (GFCI outlet) at least
11.5 ft (3.5 m) away from the pool, out of direct
sunlight, rain or inclement weather, and with adequate
Wi-Fi strength.
Figure 2. Charging Location
2. Plug charger into a GFCI outlet.
11.5 ft
(3.5 m)
3. Tilt charger (A) and connect (B) to cleaner. When
correctly connected, the cleaner will "beep" and
begin charging.
< 5 h
Figure 3. Connect Cleaner and Plug in Cleaner
IMPORTANT
• Start the cleaner, then fully submerge in the water to start
cleaning cycle.
• At the end of each cycle, remove the cleaner from the pool
and recharge.
• Clean the filter canister after each cleaning cycle.
• Do not leave your cleaner in the pool on a permanent basis.
The Polaris robotic cleaner includes a safety feature that
automatically stops the cleaner if it is powered on but not
submerged in water. For pools equipped with a beach area,
this safety feature is programmed to drive the cleaner in
reverse and back into the pool when the impeller is out of
the water.
4. Before using the cleaner for the first time, fully charge
the cleaner until the battery indicator shows solid green.
5. Dry the cleaner and charging contacts, then charge
the cleaner before every cleaning cycle. The battery
indicator slowly blinks orange while charging, slowly
blinks green when it can be used to run a cycle, and
shows solid green when fully charged.
6. You can check the current charge level in the app
whenever the cleaner is charging and connected to
WiFi.
7. The cleaner goes into deep sleep after 8 days of
inactivity to protect the battery. When all indicators are
off, the cleaner is in sleep mode. Re-set the cleaner to
wake up. If this does not work, see Troubleshooting.
ENGLISH
B
A
"BEEP"
Page 7
