ENGLISH
Failure to comply with the following warnings could cause damage to pool equipment or personal injury.
• The Polaris cleaner must be installed and operated as specified.
• This product is intended for use with permanently-installed pools. Do not use with storable pools. A permanently-installed pool
is constructed in or on the ground or in a building such that it cannot be readily disassembled for storage. A storable pool is
constructed so that it is capable of being readily disassembled for storage and reassembled to its original integrity.
• Clean the filter canister in the Polaris cleaner after each use.
• Do not use the product in your pool if the water temperature is above 95°F (35°C) or below 55°F (13°C).
USE OF THE POLARIS ROBOTIC CLEANER IN A VINYL LINER POOL
• Certain vinyl liner patterns are particularly susceptible to rapid surface wear of pattern removal caused by objects coming into
contact with the vinyl surface, including pool brushes, pool toys, floats, fountains, chlorine dispensers, and automatic pool
cleaners. Some vinyl liner patterns can be seriously scratched or abraded simply by rubbing the surface with a pool brush. Ink
from the pattern can also rub off during the installation process or when it comes into contact with objects in the pool. Zodiac
Pool Systems LLC is not responsible for, and the Limited Warranty does not cover, pattern removal, abrasion or markings on
vinyl liners.
Section 2. Cleaner Specifications
2.1
General Specifications
The general specifications for the cleaner are as follows:
WARNING
Only use the battery charger supplied with the cleaner.
Charger Supply Voltage
Supply Voltage
Battery Capacity
Charging Power
Cleaner Size (WxDxH)
Weight of Cleaner
Packed Weight
Filtration
Cycle Lengths
Charge Temperature
Water Temperature Range
Operating Depth
*Class II: An appliance with double insulation or reinforced
insulation that does not require grounding.
Page 6
SAVE THESE INSTRUCTIONS
110-240 VAC; 50/60 Hz
Class II*
29.4 V DC
6.4 Ah
29.4 W
16 x 16.5 x 11 inches
(41 x 42 x 28 cm)
19 lbs. (8,9 kg)
26 lbs (11.9 kg)
All-purpose filter canister
Variable programming
Max 95°F (35°C)
Min 40°F (5°C)
Max 95°F (35°C)
Min 55°F (13°C)
Max 13 ft. (4m)
Min 15 in. (40 cm)
Polaris
FREEDOM
SC Cordless Robotic Cleaner | Owner's Manual
®
™
CAUTION
2.2
Contents
The packaging should contain the following items:
• Polaris Cleaner
• Removal Hook
• Charger
Figure 1. Contents
