Fig. 9. Front and rear views of the battery cabinet tower version
measuring 836.5 mm high.
Fig. 10. Front and rear views of the 130 mm high rack version
battery module (3U).
84
Battery fuses (F8)
Battery Grounding
connectors
Battery input
Battery output
terminals
terminals
+ N – + N –
Seccionador baterías
Earth terminal (T)
Battery fuses (F8)
Stabilising support
Immobiliser
